| Keyboard |
Number of Keys: 61
Touch Response: 3 sensitivity levels, off |
| Sound Source |
AIX
Polyphony: 64 |
| Toned |
900 (including 100 Lyric Tones) |
| Layer |
3 (Upper1/2, Lower1) |
| Split |
Yes |
| Sustain |
Yes |
| Vocal Synthesis |
Lyric Tones: 100 Preset / Max. 150 Users
Lyric Tone Performance Modes: Phrase Mode, Note Mode
Vocalist Types: 22 Presets / 1 User
Vocalist Format: 44.1 kHz, 16 bit, Mono |
| Effects |
Reverb: 24 (+Preset for each tone)
Chorus: 12 (+Preset for each tone)
Delay: 15 (+ Preset for each tone)
DSP Effect: 100 (+Preset for each tone)
Master EQ: 10 Presets + 1 User |
| Volume Sync EQ |
Yes |
| Surround |
Yes |
| Accompaniment |
Number of Rhythms: 243
User Rhythms: 50
One Touch Presets: 243
Chord Mode: CASIO Chord, Fingered 1, Fingered 2, Fingered On Bass, Fingered Assist, Full Range
Rhythm Elements: Intro, Normal, Normal-Fill, Variation, Variation-Fill, Ending, Synchro Start, Synchro Stop |
| Metronome |
Beat Bell: Off, 1 to 9 (beats)
Tempo Range: 20 to 255
Tap Tempo: Yes |
| Arpeggiator |
150 |
| Auto Harmonize |
12 |
| Songs |
User Songs: 10
Part Off: Left Hand, Right Hand, Both Hands
Demo Songs: 2
USB Memory Song Playback (981 songs max.) |
| Registration |
Max. 64 setups (4 setups × 16 banks)
Freeze Function: Yes |
| My Set Up Function |
Yes |
| Transpose |
－12 two ＋12 Semitones |
| Octave Shift |
ー3 to +3 Octaves |
| Tuning |
A4 = 415.5 Hz to 440.0 Hz to 465.9 Hz |
| Scale Setting |
Equal Temperament + 16 Variations |
| MIDI Recorder |
Yes
Songs: 5
Tracks: 6
Memory Capacity: 40,000 Notes (per song) |
| Sampling Function |
Input Method: Audio In / Media (WAV)
Sampling Type / Time: Sampling Melody × 1 / Approx. 10 sec., Sampling Drum Set ×1 / Approx. 3 sec.
Format: 44.1kHz, 16 bit, Stereo
Loop Functionality |
| Pitch Bend Wheel |
Yes (0 to 24 semitones) |
| Knobs |
3 (for parameter control) |
| LCD |
Yes
Type: Full-dot
Back Light: Yes (white) |
| General MIDI |
Yes |
| Wireless Functionality |
Bluetooth® version 5.0
AUDIO Profile: A2DP, Supported Codec: SBC
MIDI Profile: GATT (MIDI over Bluetooth® Low Energy)
(using supplied Wireless MIDI & Audio Adapter WU-BT10) |
| Connection to App |
Supported App: Lyric Creator, CASIO MUSIC SPACE |
| Terminals |
PHONES: Stereo Mini Jack
LINE OUT (L/MONO, R): Standard
PEDAL 1: Standard
PEDAL 2/EXPRESSION: Standard
AUDIO IN: Stereo Mini Jack
USB Type A (TO DEVICE)
Micro USB Type B (TWO HOST) |
| Strap Pin |
Yes |
| Speakers |
(13cm x 6cm) x 2
Horizontal Bass Reflex: Yes |
| Amplifiers |
2.5W + 2.5W |
| Power Supply |
AC Adapter: AD-A12150LW (DC 12V)
Battery: AA-size alkaline batteries x 6 or AA-size rechargeable nickel metal hydride batteries* x 6
Battery Life: Approximately 3 hours continuous operation
Actual continuous operation time may be shorter due to battery type,
performance type, and usage environment. * Measured values while using eneloop batteries. eneloop is a trademark of the Panasonic group.
|
| Power Consumption |
7.5 W |
| Dimensions |
930x258x91mm |
| Weight |
4.7 kg |
| Included accessories |
AC adapter (AD-A12150LW), Wireless MIDI & Audio Adapter (WU-BT10), Music stand, Strap lock |
Optional accessories
(sold separately) |
Pedals (SP-3, SP-20), Headphones (CP-16), AC adapter (AD-A12150LW), Special stand (CS-2X), Benches (CB-7, CB-30BK, CB-30BN), Carrying case (SC-650B), Wireless MIDI & Audio Adapter (WU-BT10) |
