SKU:DD-8
Pro-standard multi-mode delay with powerful built-in features
Highlights
- The most advanced BOSS compact delay pedal ever
- 11 versatile modes, including basic digital delay, vintage echos, shimmer, mod, looper and more
- Looper features up to 40 seconds of recording time, overdub, and three-pedal operation with external footswitches
- Three newly developed delay types: Warm, +RV (delay+reverb) and GLT (rhythmic delay)
- Up to 10 seconds of delay time with tap tempo input
- Carryover switch determines whether delay trails continue or stop when the effect is bypassed
- True stereo I/O and three selectable output modes (independent, panning and wide stereo)
- Smart I/O jacks support a wide range of connectivity options (mono, stereo, wet/dry, wet only and more)
- Supports external control for up to two footswitches or an expression pedal
- Unique Twist function in each delay mode via an external footswitch
- BOSS five-year warranty
Full description
Versatile sonic range, maximum delay effect
Introducing the DD-8, the most comprehensive and feature-rich BOSS delay pedal ever. This pedal delivers more of everything—more great sounds, more delay time, more control options, and more connectivity. And it does it all in a standard BOSS pedal that fits perfectly into any mono or stereo setup. Eleven modes give you delay tones from the most basic to the most exotic, plus a looper with infinite overdub that supports external control. For versatility and size, there's no better delay pedal than the DD-8.
Delay modes
Analog —Classic analog BBD delay sound.
Standard —Crystal clear digital delay.
Tape —Vintage tape-based delay sound.
Warm —Digital delay with a softer sound.
Reverse —Backward delay for cool psychedelic effects and other unique sounds.
+RV —Digital delay with reverb added.
Shimmer —Pitch-shifted delays with rich and shimmering texture.
Mod —Digital delay with modulation added on repeats.
Warp —Unique delay with expressive pedal control. Holding the pedal down increases feedback and level, allowing for ambient swell effects.
GLT —Newly developed delay that creates glitchy machine gun effects when you press the pedal. Adjust the Feedback and Time knobs for a wide range of sounds.
Loop —Loop recorder with overdub and up to 40 seconds of recording time with mono input (20 seconds with stereo input).
Specifications
Nominal Input Level
-20 dBu
Input Impedance
1 M ohm
Nominal Output Level
-20 dBu
Output Impedance
1k ohms
Recommended Load Impedance
10 k ohms or greater
Bypass
Buffered bypass
Controls
MODE knob, TIME knob, FEEDBACK knob, E.LEVEL(Effect Level) knob, CARRYOVER switch, Pedal switch,
Indicator
CHECK indicator (Used for indication of check battery)
Connectors
INPUT-A(MONO)/INPUT-B jack: 1/4-inch phone type, OUTPUT-A(MONO)/OUTPUT-B jack: 1/4-inch phone type, TEMPO/EXP jack: TRS 1/4-inch phone type, DC IN jack
Power Supply
Alkaline battery (9 V, 6LR61), AC adapter (PSA series: sold separately)
Current Draw 100 mA
Expected battery life under continuous use Alkaline: Approx. 3.5 hours
*These figures will vary depending on the actual conditions of use.
Accessories
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information") Dry battery (9 V, 6LR61)
Options (sold separately) AC adapter: PSA series, Footswitch: FS-5U, FS-6, FS-7, Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
SIZE AND WEIGHT
Width 73 mm (2-7/8 inches)
Depth 129 mm (5-1/8 inches)
Height 59 mm (2-3/8 inches)
Weight (including battery) 440 g (1 lb)
* 0 dBu = 0.775 Vrms
* The specifications are subject to change without notice.
