• Compact analogue mixer with 8 channels, BlueTooth and 16 effects
• USB I/O for audio playback and stereo recording
• Dedicated Bluetooth channel with "mix-minus" for feedback-free phone pairing
• 4 headphone outputs with independent volume control
• 16 built-in Alesis multi-effects with dedicated return channel
• TRS Main, Tape and AUX outputs
• 4 microphone input channels with phantom power and balanced line inputs
• 2 stereo input channels with balanced 1/4” TRS connectors
• Two-band EQ on all channels
• 2-track inputs with separate routing: Main Mix or headphone output
• 8-segment LED VU meter

Description

8-channel mixer with USB, Bluetooth and effects

The Alto Professional TrueMix 800 FX is a compact mixer with built-in DSP effects that delivers all the essential features you need for home recording, live streaming, podcasting or performing. The TrueMix 800 FX features 16 effects provided by Alesis itself, including chorus, flanger and a selection of high-quality delays and reverbs. There's also a convenient Bluetooth channel for easy streaming from your iOS/Android devices. Unique to the TrueMix series, the Bluetooth channel also supports feedback-free phone pairing using "mix-minus" technology.

There are 8 analog inputs with high headroom to ensure minimal noise. The 4 microphone input channels offer XLR inputs that can accept both dynamic and condenser microphones with 48v phantom power. These channels also have balanced TRS line inputs for connecting instruments and other line level signals. There are also two stereo input channels, each with dual balanced TRS inputs. All channels have a two-band EQ with color-coded knobs that make it easy to adjust the signal, even in low light conditions. There are even extra covers included so you can fully customize the look of your TrueMix 800 FX!

Connect the TrueMix 800 FX to your computer via USB 2.0 for plug and play connectivity on Windows and macOS. The TrueMix 800 FX is a feature-packed compact audio mixer that's perfect for use on the go, in the home studio or in the practice room.

Videos

Specifications

• Compact analogue mixer with 8 channels, BlueTooth and 16 effects
• USB I/O for audio playback and stereo recording
• Dedicated Bluetooth channel with "mix-minus" for feedback-free phone pairing
• 4 headphone outputs with independent volume control
• 16 built-in Alesis multi-effects with dedicated return channel
• TRS Main, Tape and AUX outputs
• 4 microphone input channels with phantom power and balanced line inputs
• 2 stereo input channels with balanced 1/4” TRS connectors
• Two-band EQ on all channels
• 2-track inputs with separate routing: Main Mix or headphone output
• 8-segment LED VU meter
• Extra button caps included in the box
• Frequency response: 20 Hz – 22 kHz (±1 dB)
• THD+N: < 0.005% (@ 4 dBu, 1 kHz)
• Gain range: Microphone inputs (Channel 1-2): 0 – 50 dB, Line inputs (Channel 1-2): 15 dBu – 35 dBu, Line inputs (Channel 3-6): -20 dBu – +20 dBu
• Max voltage gain: 70 dB (MIC INPUT to MAIN MIX OUTPUT), 80 dB (MIC INPUT to CTRL ROOM / PHONE OUTPUT), 60 dB (MIC INPUT to MON SEND)
• SNR: > 110 dBu
• Crossover Frequency: Adjacent Inputs: < -80 dB @ 1 kHz, Inputs to Outputs: < -75 dB @ 1 kHz (stereo L/R, channels 1-2, panned hard left or right)
• Phantom Power: +45 ~ +49V with on/off button
• Impedance: Mic inputs: 3.9 kΩ, All other inputs: > 10 kΩ, Aux outputs: 1 kΩ, All outputs: 120 Ω
• Equalizer: High: ±15 dB @ 12 kHz, Low: ±15 dB @ 80 Hz
• Bluetooth: A2DP, Bluetooth 5.0, 2402 MHz – 2480 MH, Range: 30.5 m
• Connectors: 6 1/4" TRS outputs, 6 1/4" TRS stereo L/R inputs, 4 1/4" TRS headphone outputs, ) 1/4" TRS mono inputs, 1 Standard RCA L/R input, 1 Standard RCA L/R output, 4 XLR inputs, 1 USB type-B input, 1 DC power input
• Power: DC connection, Voltage: 18V, 1.2A, 18W consumption
• Dimensions: 305 x 238.5 x 79 mm
• Weight: 2.04 kg
