Full description

The newly developed Virtual Multi-Contact system replicates the keyboard performance of a vintage Hammond Organ, allowing the musician to experience the distinctive Hammond feel in every detail. For even greater versatility, our optional Hammond MIDI pedalboards such as the XPK-130G, XPK-200G or XPK-200GL can trigger this Virtual Multi-Contact system for the pedal sound.

Specifications

SOUND ENGINE [Organ Section] : MTW1 (Modelled Tone Wheel I), Polyphony: 61 (Tone Wheel Organ)
[Piano/Ensemble Section] : Sampling Sound Engine, Polyphony: 128
[Mono Synth Section] : Analog Modeling Synthesizer, Monophonic
KEYBOARDS SK PRO: C1 to C6 61-keys / SK PRO-73: F1 to F7 73-keys, velocity, semi-weighted, Square-front ("Waterfall"-style)
ORGAN SECTION [Parts] : 3 (Upper, Lower, Pedal)
[Drawbars] : 1 set, 9 pitches
[Voicing] : Upper & Lower: 8 (A-100, B-3, C-3, Mellow, Vx, Farf, Ace, Pipe) Pedal: 3 (Normal, Muted, Pipe)
[Percussion] : Buttons: On, Volume Soft, Decay Fast, Third Harmonic
PIANO/ENSEMBLE SECTION Component: 4, LFO: 2
MONO SYNTH SECTION [Oscillator] : 6 types (Duo, Unison, Pulse, Sync, FM, Noise)
[Filter] : 4 types (LP12, LP24, HP12, HP24), Resonance, Drive
[Modulator] : LFO: 1, EG: 2 (Pitch & Filter, Amplitude
EFFECTS [Organ Section] : Vibrato & Chorus, Multi Effect 1, Overdrive, Multi Effect 2, Matching Transformer, Leslie, Equalizer & Tone Control
[Piano/Ensemble Section] : For each section: Multi Effect 1, Overdrive, Multi Effect 2, Equalizer
[Mono Synth Section] : Multi Effect 1, Overdrive, Multi Effect 2, Equalizer
[Master] : Equalizer, Reverb
KEY MAP [Internal zone] : Transpose, Octave, Split, Pedal To Lower, Allocate, Pedal Sustain
[External Zones] : 3 Zones (assignable to each keyboard)
CONTROLLERS Pitch Bend wheel, Modulation wheel, Portamento, Leslie (Bypass, Stop, Fast)
MEMORY [Favorites] : 10 banks x 10 numbers (Combination), 10 numbers (Page)
[Combination] : Factory: 100, User: 100, Bundle: 100, Manual
[Organ Patch] : Factory: 100, User: 100, Bundle: 100
[Piano/Ensemble Path] : Factory: 300, User: 400
[Mono Synth Patch] : Factory: 100, User: 100, Bundle: 100
[Custom Tone Wheel] : Factory: 4 x 3, User: 4 x 3
[Custom Pedal Registration] : Factory: 3, User: 3
[Custom Pipe] : Factory: 3, User: 3
[Custom Cabinet] : Factory: 8, User: 8
STORAGE Internal Memory, USB Flash Drive
DISPLAY 320 x 240 pixels
CONNECTIONS [MIDI] : IN, OUT
[USB] : To Host
[Audio] : Line Out L, R, Headphones, Individual 1, 2, Rotary Out, Organ Pedal Out, Aux In (with Volume control)
[Leslie] : 11-pin, 1 and 3 channels available
[Others] : Foot Switch 1, Leslie Switch, Foot Switch 2, Damper Pedal, Expression Pedal
RATED POWER CONSUMPTION 22W
DIMENSIONS SK PRO: 1004mm(W) x 322mm(D) x 109mm(H) / SK PRO-73: 1170mm(W) x 322mm(D) x 109mm(H)
WEIGHT SK PRO: 9.3 kg / SK PRO-73: 11 kg
ACCESSORY Power Cord

Manual available online: English, German, Dutch and French
